RMU Series Trip Assembly

Get a Price/Quote

MOQ : 100 Pieces

RMU Series Trip Assembly Specification

Thickness
Standard as per RMU specification

Magnet Grade
Industrial Grade

Machine Type
Ring Main Unit (RMU)

Magnet Category
Electromagnetic Trip Assembly

Composite
Metallic and Polymeric

Shape
Rectangular / Modular Assembly

Application
Protection and Tripping Mechanism in Ring Main Unit

Size
Standard/Customized (based on RMU model)

Weight
Approx 12 kg (depending on design)

Color
Multi-color Components (as shown in image)

Function
Trips the circuit in abnormal/fault conditions

Capacity
Suitable for Medium Voltage (MV) RMU applications

Brand Required
Customized / As per RMU Manufacturer

Material
Electromechanical Components, Copper, Insulation Material

Service Life
Designed for more than 10,000 Operations

Maintenance
Low Maintenance Required

Standards
Complies with IEC 62271-200 / IS Standards

Operating Voltage
Up to 36kV (as per RMU type)

Operating Mechanism
Electromagnetic Trip Mechanism

Mounting Type
Panel Mounted / RMU Integrated

Insulation Resistance
>= 1000 M at 1 kV

Ambient Operating Temperature
-10C to +55C

Current Rating
As per RMU rating (typically up to 630A)

Contact Type
Silver/Plated Copper Contacts

Response Time
<80 ms

RMU Series Trip Assembly Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash Advance (CA)

Delivery Time
10 Days

Main Domestic Market
All India

About RMU Series Trip Assembly

We are distinguished in providing a wide array of RMU Series Trip Assembly. It is design in a compact size of material to prevent form nay breakdown issue in future. This assembly is to connect and measure with transformer protection function. RMU Series Trip Assembly is highly reliable and easy to maintain. It is also useful to reduce down the cost of wiring. It is suitable for medium voltage power distribution and to trip the RMU circuit breakers.

Engineered for Reliable Circuit Protection

The RMU Series Trip Assembly delivers dependable operation with its advanced electromagnetic trip mechanism, responding to fault conditions in less than 80 milliseconds. Its robust design and compliance with international standards guarantee long-term safety and reliability for medium voltage applications.

Versatile Integration and Customization

Designed for both panel-mounted and RMU integrated applications, this trip assembly can be tailored to specific manufacturers' requirements. With options for standard or custom sizes and configurations, it seamlessly fits various RMU models and ensures compatibility with your system's unique needs.

Low Maintenance, Long Service Life

Built for endurance, the RMU Series Trip Assembly requires minimal upkeep while being capable of over 10,000 operations. Industrial-grade materials and precise engineering contribute to its exceptional durability, minimizing downtime and maintenance costs for utility providers and industrial users alike.

FAQ's of RMU Series Trip Assembly:

Q: How does the RMU Series Trip Assembly operate during fault conditions?

A: The RMU Series Trip Assembly utilises an electromagnetic mechanism that detects abnormal or fault situations in the Ring Main Unit (RMU) and reacts by tripping the circuit in under 80 milliseconds, ensuring rapid isolation and system protection.

Q: What are the benefits of using an RMU Series Trip Assembly in medium voltage applications?

A: This assembly delivers fast tripping, high reliability, and insulation resistance of over 1000 M, which are critical for safeguarding medium voltage systems. Additionally, it prolongs the life of your RMUs with its low maintenance requirements and durable construction.

Q: When should the RMU Series Trip Assembly be replaced or maintained?

A: The assembly is designed for over 10,000 operations and requires little maintenance. However, periodic inspection according to your RMU's routine service schedule is recommended to ensure optimal performance and safety.

Q: Where can the RMU Series Trip Assembly be installed?

A: This trip assembly is suitable for RMUs mounted in panels or integrated directly into RMU systems. Its modular and rectangular design allows it to adapt to standard or customized RMU configurations.

Q: What standards does the RMU Series Trip Assembly comply with?

A: It meets IEC 62271-200 and relevant IS standards, ensuring adherence to international and national safety and performance benchmarks for medium voltage switchgear components.

Q: How can I ensure compatibility with my RMU system?

A: The assembly can be customized as per the RMU manufacturer's specifications. By providing your RMU model details, you can ensure the trip assembly fits and functions correctly within your system.

Q: What is the primary usage of the RMU Series Trip Assembly?

A: Its main application is to serve as a protection and tripping mechanism in medium voltage Ring Main Units, automatically isolating the circuit to prevent further damage during abnormal or fault conditions.

Tell us about your requirement
